ASME B16.23-2021

SALE
ASME-B16.23-2021

Original price was: $116.00.Current price is: $69.00.

Cast Copper Alloy Solder Joint Drainage Fittings–DWV

Published by ASME International, 03/18/2022

Preview

PDF

All of our standards are only available in PDF (Portable Document Format), an electronic, downloadable format.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.

Category:

ASME B16.23, 2021 – Cast Copper Alloy Solder Joint Drainage Fittings–DWV

ASME B16.23 establishes specifications for cast copper alloy solder joint drainage fittings, designed for use in drain, waste, and vent (DWV) systems. These fittings are designed for use with seamless copper tube conforming to ASTM B306, Copper Drainage Tube (DWV), as well as fittings intended to be assembled with soldering materials conforming to ASTM B32, or tapered pipe thread conforming to ASME B1.20.1.

This Standard is allied with ASME B16.29, Wrought Copper and Wrought Copper Alloy Solder Joint Drainage Fittings – DWV.

It provides requirements for fitting ends suitable for soldering. This Standard covers:
(a) description
(b) pitch (slope)
(c) abbreviations for end connections
(d) sizes and methods for designing openings for reducing fittings
(e) marking
(f) material
(g) dimensions and tolerances

General Product Information:

Document Type PDF
ISBN
Pages 58
Document Language English
Publisher American Society of Mechanical Engineers (ASME)
Status Current
